    High Accuracy Fast Adjustment Book Box Assembly Machine production speed 18-27pcs/min

    Ask Lasest Price
    Brand Name : Lishunyuan
    Model Number : LY-1000SXH
    Price : USD 30000per/set- USD 35000per/set
    Payment Terms : L/C, T/T
    Supply Ability : 20sets/month
    Delivery Time : 20days
    • Product Details
    • Company Profile

    High Accuracy Fast Adjustment Book Box Assembly Machine production speed 18-27pcs/min

    Full-automatic Book Box Assembling Machine production speed 18-27pcs/min

    The book style box assembly machine is the preferred equipment for book style box and cosmetic box manufacturers to reduce production costs. The machine uses mechanical arm to automatically position and spray glue, which can be adjusted according to the size requirement of the product.
    Technical Parameters
    Case maker size
    W: 400 - 130mm
    L: 900 - 130mm
    Paper thickness
    80 - 300g/m2
    Max. paper stacking height
    800mm
    Cardboard thickness
    1 - 3mm
    Finished box size (W*L*H)
    L: 100 - 600mm
    W: 80 - 400mm
    H: 15 - 110mm
    Production rate
    18 - 27pcs/min
    Positioning accuracy
    ±0.3mm
    Power Supply
    220V
    Constant power
    6KW
    Air pressure
    0.6 - 0.8MPa
    Nozzle quantity
    1
    Machine weight
    800KG
    Machine size
    L3400 * W2000 * H1900mm

    Product Features:

    Automatic & Informatization & Intelligentization
    1,High Safety performance and fast adjustment.
    2,Simple and convenient to use, high in efficiency.
    3,Digital input is used for glue spraying, box pressing and position shifting.
    4,The processing speed is fast, with strip spraying method adopted.
    5,Glue dispensing procedure is automated, diversified and simplified.
    6,The inner box pressing procedure is stable and accurate.
    7,High stability, high accuracy and long service life.
    FAQ:
    1.What about machine warranty?----1 year warranty including free machine parts replacement ( consumables are not included).
    2.What is the production time while placing order?---- Within 7-30 workdays.
    3.Do you have stock product to sell?----Normally we do,it depends on how many sets do you need .
    4.What is your lead time?----Within 5-30 workdays
    5.Does the packing strong?----Yes, of course! All of our export packing is with strong wooden case,all are confirm to export packing standard.
    6.How about after-sales service process?----When your machine has problem, just contact your sales and we will solve your problem ASAP.
    7.Are you a manufacturer?----Yes, we are a manufacturer with over 18 years professional experience .
    8.What is the minimum quantity for order?----1 set, we done business step by step with high quality products and excellent services.
    9.Do you inspect the finished products?----Yes, each step of production products will be inspection by our QC department and the running inspection video will be sent to to you for your verification before shipping.
    High Accuracy Fast Adjustment Book Box Assembly Machine production speed 18-27pcs/min
