    New Design High Accuracy ±0.05 Intelligent Automatic Rigid Box Making Line With Stable Speed 20-25pcs/min

    Ask Lasest Price
    Brand Name : LIshunyuan
    Model Number : LY-1200CM
    Payment Terms : L/C, T/T
    Supply Ability : 20sets/month
    Delivery Time : 20days
    Price : USD 190,000.00-USD 230,000.00set
    Certification : CE
    • Product Details
    • Company Profile

    New Design High Accuracy ±0.05 Intelligent Automatic Rigid Box Making Line With Stable Speed 20-25pcs/min

    New Design High Accuracy ±0.05 Intelligent Automatic Rigid Box Making Line
    LY-HB1200CM is our latest intelligent high speed rigid box production line with IOT function, which is suitable for the production of various rigid boxes such as jewelry boxes, mobile phone boxes, gift boxes, cosmetics boxes, watch boxes, wine boxes and etc.The whole line is safer and looks more beautiful with new design.
    Technical Parameters
    Paper Size
    W: 95 - 600mm
    L: 180 - 880mm
    Paper thickness
    80-300g/m2
    Max.paper stacking height
    800mm
    Cardboard thickness
    1-3mm
    Finished box size (W*L*H)
    L: 100 - 600mm
    W: 80 - 400mm
    H: 15 - 110mm
    Ear overlapping size
    7 - 100mm
    Ear cross ear folding size
    120mm
    Production rate
    20 - 25pcs/min
    Setting time
    10 - 15mins
    Precision
    ±0.05mm
    Power Supply
    380V/50Hz
    Max power
    37KW/380V
    Air pressure
    0.5-0.7mpa/320NL/min
    Glue tank volume
    30KG
    Machine weight
    7500KG
    Machine size
    L8000*W1700*H3300mm

    Product Features:

    Automatic & Informatization & Intelligentization
    1. Suitable for the production of various rigid boxes
    2. Adopt Japanese industrial camera & YAMAHA robot arm with the accuracy of 在±0.05mm;
    3. Intelligent setting (memory function) and the time of job change-over is 10-15min;
    4. Parameters setting by computer;
    5. The folding-in depth up to 100mm;
    6. Automatic paper & greyboard feeding;
    7. 24-hour preheating function & suitable for water glue & jelly glue;
    8. Adopt Japanese servo motor control system;
    9. Automatic box holding, lifting & feeding
    10. Suitable for the production of luxury boxes with ear to ear or ear cross ear;
